Multi Straight Abutment
November 14, 2023
Multi Temporary Abutment
November 14, 2023
Multi Angled Abutment
- Using a delivery holder
- Recommended torque for fastening : ≤ 30Ncm
- Packaging and order : There are two pieces in the package (abutment with screw).
and for order use US1MA code with the desired size - Scale of pic is 1:1.5mm
- 2 Kinds of angulations, 17° and 30°
- Korean implant
Diameter Ø 4.8
Angled 17°
Code | G/H | Connection Type | Crown Connection |
US1MA-481710H | 1 | Hex | Non-Hex |
US1MA-481720H | 2 | Hex | Non-Hex |
US1MA-481730H | 3 | Hex | Non-Hex |
US1MA-481740H | 4 | Hex | Non-Hex |
Diameter Ø 4.8
Angled 30°
Code | G/H | Connection Type | Crown Connection |
US1MA-483010H | 1 | Hex | Non-Hex |
US1MA-483020H | 2 | Hex | Non-Hex |
US1MA-483030H | 3 | Hex | Non-Hex |
US1MA-483040H | 4 | Hex | Non-Hex |
Related products
-
Fixture Implant
Optimized Design for Any Surgery
• Simple surgical protocol helps reduce chair time
• Stabilized in use to Extraction Socket
• Enable Early Loading in upper posteriorDual & Deep Thread
• Enhancing initial stability from deeply designed Thread
• Dual thread enables Fast insertionTapered Design
• Similar design of natural tooth
• Proper load distribution harmonized with anatomy -
Temporary Abutment
- Using a 1.28 Hex driver
- Recommended torque for fastening : ≤ 30Ncm
- Packaging and order : There are two pieces in the package
- (abutment with screw). and for order use US1TA code with the desired size
For making provisional restoration - Available in both hex and non-hex
- Scale of pic is 1:1.5mm
- Korean implant
-
Impression Coping Transfer
- Using a 1.28 Hex driver
- Recommended torque for fastening : ≤ 5Ncm
- Packaging and order : There are two pieces in the package
(impression with guide pin). and for order use US1IC code with the desired size - transfer : Used for Closed Tray (Transfer) technique
- Scale of pic is 1:1.5mm
